Stellaris 2D covers a variety of diagnostics in 2Dand Ceph with one shot ceph images and programs for panoramic examinations.
The minimalist, elegant, space-saving design allows installation of Stellaris 3D in areas where conventional devices would not fit.
Control of the system is available from your PC screen as well as on the unit's touchscreen, allowing straightforward program selection with hints for correct positioning.
Dedicated linear sensor for the best image quality.
Adult and, more importantly, child programs are crucial for ECO low dose examinations, allowing high diagnostic image quality for both overview and demanding diagnostic tasks.
Ambient lighting creates a comfortable atmosphere for the patient and allows to monitor the unit status from a distance.
Latest sensor design, technology and unit robotics have been used to achieve high precision level of detail and smooth, quiet operation. The machine allows for repeated exposures without having to wait.
Sensor Technology
CMOS Flat Panel, CSI Flat Panel for ceph
Pixel size
100 µm
Focal Spot
0.5 (IEC 336 / 1997)
Tube Voltage
60 - 86 kV
Tube Current
2.5 - 10 mA
Exposure time 2D
4.6 - 14.2 seconds
Exposure Time Ceph One-Shot
0.2 - 4 seconds
Ceph Image Size
240x300 mm
Weight
109kg without ceph, 137kg with ceph
Panoramic Programs
in total 9: adult pano, child pano, dentition, BW, TMJ, sinuses, half dentition left, half dentition right, anterior teeth.
Ceph Programs
LL 30x24, LL18x24, AP, PA, Carpus
Patient Sizes
Child, teenager, woman, man
Software
OrisWin DG Suite
Features
Panoramic, panoramic upgradable to 3D and ceph, panoramic with
ceph upgradable to 3D.
Footprint
140x110 cm without CEPH, 240 x 110cm with CEPH
Patient position
Standing or sitting
Wheelchair acessible
Yes
